AHD 40mm itsetasoittuva 60m putken viemärikamerajärjestelmä
AHD 40mm itsetasoittuva 60m Pipe Sewer Camera System on laadukas ja kestävä työkalu putkien ja viemärien tarkastamiseen. Sen itsetasaava ominaisuus varmistaa tarkan ja luotettavan katselun, joten se on tärkeä työkalu LVI- ja rakennusalan ammattilaisille
The AHD 40mm Self-leveling 60m Pipe Sewer Camera System is a high-quality and versatile tool for inspecting pipes, sewers, and other hard-to-reach areas. With a 40mm camera head and self-leveling capabilities, it can navigate through tight spaces and provide clear, high-resolution images. This system is ideal for plumbers, contractors, and maintenance workers who need to quickly and accurately diagnose issues in underground piping systems.
Overview of 40mm self-leveling Camera
______
| Self-leveling image no matter what angle the camera is at, the image is always upwards. |
| 1/3 CMOS, 1.3MP pilex FHD , waterproof IP68 |
| Waterproof IP68 |
| 10 inch IPS lcd screen |
| DVR control box with audio ,video recording and photography function |
| USB wireless keyboard to typewrite the words |
| Built in 8800mA li-ion battery inside |
| Digital meter counter function, error is less than 1% |
Main Part 1: 40mm self-leveling camera head
______
| Camera size | 40mm x 77mm |
| Camera pixel | Sensor 1/3" CMOS, 1.3MP pixel |
| Waterproof level | Waterproof IP68 |
| Camera range | View range 120° |
| Light | 12pcs high light LED lighting adjustable |
| Kobling | Detachable with aviation plug type connection to Cable Reel |
| Materiale | Lens window sapphire glass & stainless steel |
Main Part 2: DVR control unit
______
| Skjermstørrelse | 10"HD IPS LCD Screen |
| Waterproof level | Waterproof keys & waterproof panel |
| Funksjon | Video, auido and photography function DVR |
| Keyboard | USB wireless Keyboard real time typewriting |
| Meter counter | Digital meter counter function, display on the screen |
| Battery | 8800mA rechargeable Li-ion Battery Pack |
| Battery level indicator |
Main Part 3: Cable reel
______
| Meter counter | Digital meter counter |
| Materiale | Fiberglass push rod cable |
| Cable diameter | 7mm |
| Cable length | 60m |
| Reel size | 51 x 25 x 64cm |
Søknader
______
Detect and identify pipe damage:
Detect leaks and blockages in the water supply pipeline system to ensure the normal operation of the work within the pipeline.
Evaluate the aging, damage, internal blockage, corrosion damage, etc. of the pipeline to provide a basis for repair and replacement.
Underground pipeline detection:
Used to locate the direction and depth of underground cables and metal pipes, and accurately measure the depth of pipes.
Assess the damage to the anti-corrosion layer outside the pipeline, locate the damage points, and provide a basis for the construction quality acceptance of the anti-corrosion layer of newly laid pipelines
