Front And Backward 20/29mm Pipe Inspection Camera
Front-and-backward pipe inspection camera features a bi-directional camera head with independent tilt control and adjustable LED illumination to inspect both upstream and downstream sections without disassembly, sealed to IP68 for operation in wet and debris-filled environments. Live video, still capture and on-board recording let technicians document bends, laterals and blockages, speeding defect localization and producing evidence-ready reports that support faster repair planning and reduced unnecessary excavation.
Overview of 20mm & 29mm front and backward camera head
______
| 8 inch IPS lcd screen, 1920X1080 resolution |
| DVR control box with audio ,video recording and photography function |
| Built in 6800mA li-ion battery inside |
| Digital meter counter function, error is less than 1% |
| Front and Rear Cameras: All-Around Observation |
Main Part 1: Front and backward camera head
______
| Camera size |
20mm x 28mm（front camera） 29mm x 46mm (backward camera) |
| Camera pixel | Sensor 1/3" CMOS, 1.3MP pixel |
| Waterproof level | Waterproof IP68 |
| Camera range | View range 120° |
| Light |
6pcs high light LED lighting adjustable（front camera） 6pcs high light LED lighting adjustable (backward camera) |
| Connector | Connected to a wire, cannot be removed |
| Material | Lens window sapphire glass & stainless steel |
Main Part 2: DVR control unit
______
| Screen Size | 8"HD IPS LCD Screen, 1920X1080 resolution |
| Waterproof level | IP68 |
| Function | 1080P format video, auido and photography function DVR |
| Meter counter | Digital meter counter function, display on the screen |
| Battery | 6800mA rechargeable Li-ion Battery Pack |
| Battery level indicator |
Main Part 3: Cable reel
______
| Meter counter | Digital meter counter |
| Material | Fiberglass push rod cable |
| Cable diameter | 5.2mm |
| Cable length | 20m-50m |
Applications
______
Detect and identify pipe damage:
Detect leaks and blockages in the water supply pipeline system to ensure the normal operation of the work within the pipeline.
Evaluate the aging, damage, internal blockage, corrosion damage, etc. of the pipeline to provide a basis for repair and replacement.
Underground pipeline detection:
Used to locate the direction and depth of underground cables and metal pipes, and accurately measure the depth of pipes.
Assess the damage to the anti-corrosion layer outside the pipeline, locate the damage points, and provide a basis for the construction quality acceptance of the anti-corrosion layer of newly laid pipelines
